Name: CE Approved Recessed LED Downlight Fire Emergency Light with 1 Watt SMD White LED and Ni-Cd Battery
Brand: Hangzhou Dreamy Technology Co.,Ltd
SKU: EL1*1AN
Price: 7.15 USD
Availability: InStock

Home > Products > Recessed Emergency Light >

CE Approved Recessed LED Downlight Fire Emergency Light with 1 Watt SMD White LED and Ni-Cd Battery

emergency lights for commercial buildings

led bulkhead emergency light

Place of Origin:

Zhejiang

Brand Name:

Zhuiming

Certification:

Model Number:

EL1*1AN

Request A Quote

Product Details

Bulb Type:

LED

Battery Type:

Ni-Cd

Material:

Electro-galvanized Steel Casing,PC Plate

Usage:

Emergency Lighting For Various Buildings

Certification:

Specifications:

1 W SMD White LED

Input Voltage:

110V-127V 50/60Hz; 220V-240V 50/60Hz

Charging Current:

40mA(Nominal)

Installation:

Ceiling Recessed Mounted

Payment & Shipping Terms

Minimum Order Quantity

300

Packaging Details

1Piece in 1 Inner Carton,20 Pieces In 1Master Carton

Delivery Time

35days after deposit

Payment Terms

L/C,T/T,Western Union

Supply Ability

10000pcs/month

Battery Backup Recessed Emergency LED Kitchen Ceiling Lights , RoHS

Get Best Price

Video

220V Rechargeable Emergency Light with 180Min Operation, Fire Retardant ABS Casing and Wall Recessed Mounted

Get Best Price

Video

LED Recessed Emergency Light 1.5W 120lm ABS Casing 3-Year Warranty

Get Best Price

3 Years Warranty LED Recessed Emergency Light ABS Casing IP20

Get Best Price

86-0571-88303726

sales@dreamylighting.com

86-0571-88302716

Contact Now

Product Description

CE Approved Recessed LED Downlights / Fire Emergency Lights 1 Watt SMD White LED

Product Overview

CE Approved Zhuiming LED Downlight Fire Emergency Light with advanced safety features and reliable performance.

Technical Specifications

Parameter	Specification
Operation	Non-maintained
Input Voltage	110V-127V 50/60Hz; 220V-240V 50/60Hz
Charging Current	40mA (Nominal)
Lamp Type	1 watt SMD White LED
Battery	Nickel-Cadmium Battery 3.6V 1.0AH
Indicator	Red LED Indicates Charging
Duration Time	More than 3 hours
Construction	Electro-galvanized Steel Casing with Corrosion Resistant Epoxy Spray Coating; PC Plate
IP Rate	IP20
Installation	Ceiling Recessed Mounted
Weight	0.5 kg
Working Temperature	-10℃ to 55℃
Size	350mm×110mm×38mm Tolerance ±0.03mm
Customization	Battery, Duration Time, Package, Wire length

Package Information

Package Details	Specification
Package	1 Set in 1 Inner Carton, 20 Sets In 1 Master Carton
Master Carton Size	405mm×370mm×235mm
Gross Weight	11.7kg
Net Weight	9.85kg

Product Images

Indicator Status Guide

Indicator	Performance	Status Meaning
Red	Lit	Charging
Green	Lit	Fully charged
Green	Slow blink (1Hz)	Manual check mode
Green	Blink (3Hz)	Automatic monthly self-check mode
Green	Quick blink (5Hz)	Automatic annual self-check mode
Yellow	Lit	Battery aging, or too short emergency time
Yellow	Slow blink (1Hz)	Battery is in short circuit or open circuit
Yellow	Blink (3Hz)	Wrong connection with lamps or not matchable lamps
Off		Emergency or stop working condition

Test Button Operation Guide

Pressed Time	Indicator Status	Check Mode
<1s	No reaction	None. To avoid mistakenly operating
1~3s	Slow blink (1Hz) in green	Check mode and discharge for 5 seconds
3~5s	Blink (3Hz) in green	Monthly self-check mode and discharge for 2 mins
5~7s	Quick blink (5Hz) in green	Annual self-check mode and discharge for 1 hour
>7s		Stop discharging to recharge again

Key Features

Over 3 hours emergency lighting after sudden blackout

Applications

For shopping malls, office buildings, government buildings, teaching buildings, residential buildings, hospitals, dormitories and similar facilities.

Certifications

Our products are guaranteed by CE and RoHS certifications.

Delivery Information

35 days on receipt of your payment
