Name: IP20 Rated Ceiling Emergency Light with 3 Hours Operation Non-maintained LED Emergency Lamp
Brand: Hangzhou Dreamy Technology Co.,Ltd
SKU: EL1X3AN
Price: 25.00 USD
Availability: InStock

Home > Products > Ceiling Emergency Light >

IP20 Rated Ceiling Emergency Light with 3 Hours Operation Non-maintained LED Emergency Lamp

non maintained emergency lighting

220V emergency light

Place of Origin:

China

Brand Name:

Zhui Ming

Certification:

Model Number:

EL1X3AN

Request A Quote

Product Details

Operation:

Non-maintained

Lamp Used:

1*3W SMD White LED

Battery:

Ni-Cd 3.6V 1.0Ah

Construction:

Electro-galvanized Steel Casing,PC Plate

IP Rating:

IP20

Warranty:

3years

Duration Time:

>3hrs

Usage:

Fire Fighting Safety Emergency

Input Voltage:

110-127V,220-240V 50/60Hz

Package:

20PCS/45*37*25CM/11.7KG/CTN

Payment & Shipping Terms

Minimum Order Quantity

300PCS

Packaging Details

1 Set in 1 Inner Carton,20 sets in 1 Master Carton

Delivery Time

45 Days after Deposit

Supply Ability

3000PCS/DAY

Fire-Retardant Recessed LED Emergency Light with 3 Hours Operation and Non-Maintained Function

Get Best Price

Video

3 Hours Autonomy Li-Ion Battery Operated Fire Resistance ABS Ceiling Emergency Light with Recessed Installation

Get Best Price

Video

Recessed LED Emergency Ceiling Light 3.6V NiCd Battery

Get Best Price

Video

6pcs 5730 LED 3W Ceiling Recessed Emergency Light IP20

Get Best Price

86-0571-88303726

sales@dreamylighting.com

86-0571-88302716

Contact Now

Product Description

IP20 Ceiling Emergency Light Permanent / Non-Permanent LED Lamp High Brightness

IP20 3 Hours Operation LED Emergency Light, Permanent / Non-permanent LED Lamp

Product Specification

Operation	Non-maintained
Input Voltage	110V-127V 50/60Hz; 220V-240V 50/60Hz
Charging Current	40mA (Nominal)
Lamp type	1 watt SMD White LED
Battery	Ni Cd Battery 3.6V 1.0AH
Indicator	Red LED Indicates Charging
Duration Time	More than 3 hours
Construction	Electro-galvanized Steel Casing with Corrosion Resistant Epoxy Spray Coating; PC Plate
IP Rate	IP20
Installation	Ceiling Recessed Mounted
Weight	0.5 kg
Working Temperature	-10℃ to 60℃
Size	350mm×110mm×38mm Tolerance ±0.03mm
Customization	Battery, Duration Time, Package, Wire length

Technical Parameters

Input Power: AC 220V-240V 50Hz / 60Hz
Light source: 3W high power LED
Emergency time ≥180 minutes
Emergency conversion time ≤1S
Emergency switching voltage: AC 144V-204V 50Hz / 60Hz
Battery: Ni-MH 3.6V / 1600mA
Installing hole size: Ф75mm

Operating Manual

Disconnect the AC power during installation.
This product should not be installed in places such as outdoors, humid and corrosive gas environments.
This product should use a separate loop-powered circuit. It should not share circuit with lighting or other electrical equipment (with a switch), to ensure this LED emergency ceiling light can be recharged normally.
To ensure the product operates normally, it should be checked regularly.
The products have been discharged before leaving the factory. So it needs to be charged 24 hours when used.
If the product is in storage or not used for a long time, it should be charged and discharged once every three months to protect the battery performance.
Please keep this manual.
