China Waterproof Emergency Light manufacturer

IP65 Fire Retardant LED Emergency Lights Wall Recessed Mounted

Product Details:
Place of Origin: China
Brand Name: Zhui Ming
Certification: CE
Model Number: EL015DN
Payment & Shipping Terms:
Minimum Order Quantity: 300 PCS
Packaging Details: 1 set in 1 Innder Box 5 sets in Master Carton
Delivery Time: 35 days after deposit
Payment Terms: L/C, T/T
Supply Ability: 3000 PCS/DAY
Contact Now

Detail Information

Operation: Non Maintained Lamp Type: 15 Pcs DIP White LED
Battery: Nickel-Cadmium Construction: PC Casing, PS Diffuser
IP Rate: IP65 Installation: Wall Recessed Mounted
Duration: 3 Hours Warranty: 3 Years

Product Description

IP65 Fire Retardant LED Emergency Lights Wall Recessed Mounted




Product Description



Parameters

Operation Non-Maintained
Input Voltage 110V-127V 50/60Hz;220V-240V 50/60Hz
Charging Current 120mA (Nominal)
Lamp Used 15 pcs DIP white LED
Battery Nickel-Cadmium Battery 3.6V 0.6Ah
Indication GREEN LED Indicates Charging
Installation Wall Recessed Mounted
Weight 1.4KG
Product Size

415mm×188mm×82mm

Duration Time

>3HRS

IP Rate IP65
Construction PC Casing, PC Diffuser
Operating Temperature -10°C to 55°C



Specification:

  1. Operation: Maintained/Non-maintained
  2. Battery: Ni-cad 3.6V0.6AH
  3. Led Application: 15pcs DIP
  4. Emergency Time: 3 Hours
  5. IP Rate: IP65 Waterproof
  6. Indicator: Green LED Indicates Charging

Application:

This product is mainly used in various types of buildings occurring sudden power outage,which can automatically supply emergency lighting . And it is mainly used for shopping malls, hotels and emergency exit of the corridor.



Operating Manual

  • Disconnect the AC power during installation.
  • This product should not be installed in places such as outdoors ,humid and corrosive gas and so on.
  • This product should use the separate loop-powered circuit.It should not share circuit with lighting or other electrical equipment (with a switch), in order to ensure this LED emergency Ceiling light can be recharged normally.
  • To ensure the product operating normally,it should be checked regularly.
  • The products have been discharged before leaving the factory.So it needs to be charged 24 hours when used .
  • If the product is in storage or not use for a long time, it should be charged and discharged once every three months, in order to protect the battery performance.
  • Please keep this manual.

Product Show:

IP65 Fire Retardant LED Emergency Lights Wall Recessed Mounted
