IP20 Ceiling Emergency Light , Emergency LED Down Light Low Energy Dissipation
IP20 Ceiling Emergency Light , Emergency LED Down Light Low Energy Dissipation
IP20 Ceiling Emergency Light , Emergency LED Down Light Low Energy Dissipation IP20 Ceiling Emergency Light , Emergency LED Down Light Low Energy Dissipation IP20 Ceiling Emergency Light , Emergency LED Down Light Low Energy Dissipation

IP20 Ceiling Emergency Light , Emergency LED Down Light Low Energy Dissipation

Product Details:
Place of Origin: China
Brand Name: Zhui Ming
Certification: CE
Model Number: EL1X3AN
Payment & Shipping Terms:
Minimum Order Quantity: 300PCS
Packaging Details: 1 Set in 1 Inner Carton,20 sets in 1 Master Carton
Delivery Time: 45 Days after Deposit
Supply Ability: 3000PCS/DAY
Contact Now
  • Detail Information
  • Product Description

Detail Information
Operation: Non-maintained Lamp Used: 1*3W SMD White LED
Battery: Ni-mH 3.6V 1.6Ah Construction: Electro-galvanized Steel Casing,PC Plate
IP Rating: IP20 Warranty: 3years
Duration Time: >3hrs Usage: Fire Fighting Safety Emergency
Input Voltage: 110-127V,220-240V 50/60Hz Package: 20PCS/45*37*25CM/11.7KG/CTN
High Light:

non maintained emergency lighting

,

220V emergency light

Product Description



IP20 Ceiling Recessed Emergency LED Down Light With 3 Hours Operation



Product Specification

Operation

Non-maintained

Input Voltage

110V-127V 50/60Hz; 220V-240V 50/60Hz

Charging Current

40mA(Nominal)

Lamp type

1 watt SMD White LED

Battery

Nickel-mH Battery 3.6V 1.6Ah 1.0AH

Indicator

Red LED Indicates Charging

Duration Time

More than 3 hours

Construction

Electro-galvanized Steel Casing with Corrosion Resistant Epoxy Spray Coating; PC Plate

IP Rate

IP20

Installation

Ceiling Recessed Mounted

Weight

0.5 kg

Working Temperature

-10℃ to 60℃

Size

350mm×110mm×38mm

Tolerance ±0.03mm

Customization

Battery, Duration Time, Package, Wire length



Characteristics:

  • Power Supply Built-in
  • Easy Installation
  • High quality electronic components
  • High-quality battery
  • High brightness
  • Low power consumption
  • Warranty:3 years

Technical Parameters:

  1. Input Power: AC 220V-240V 50Hz / 60Hz
  2. Light source:3W high power LED
  3. Emergency time ≥180 minutes
  4. emergency conversion time ≤IS
  5. Emergency switching voltage: AC 144V-204V 50Hz / 60Hz
  6. Battery: Ni-mH 3.6V / 1600mA
  7. Installing hole size: Ф75mm



Produced Shows:

IP20 Ceiling Emergency Light , Emergency LED Down Light Low Energy Dissipation 0



Function:

When the AC power is turned on, light will be off, and charging indicator will be lit. At this time,if the TEST button is pressed, the lamp and the charge indicator are light (emergency function manual testing). When disconnecting the AC power supply, charging indicator does not light, light is lit.



Application



This product is mainly used in various types of buildings occurring sudden power outage, which can automatically supply emergency lighting . And it is mainly used for shopping malls, hotels and emergency exit of the corridor.



Certificate

CE,RoHS are  safe guarantee of our products.

Tag:

ceiling recessed emergency led light

ceiling rechargeable emergency light

permanent ceiling led emergency light
